    Huayang Auto arranging Inverter Spot Welding Machine , Wire Dia 4mm Precision Spot Welder

    Wire Diameter 4mm CNC Spot Welding Machine

    1. Product description

    Wire diameter 4mm CNC spot welding machine is used for making panel mesh. Main unit: Welded with thick steel sheet and section steel, strong and concise.Welding electronic control system: PLC digital system, one time pressing, separate welding, precise control and stable function. Wire laying devices: Auto weft wire feeding device, easy to handle, high welding speed.Wire mesh opening setting: PLC digital control.Weft wire arranging: Auto arranging. Inner transformer: High efficient welding transformer, with 8 grade adjustment.

    2. Technical parameter


    ModelHY-DHW-1500HY-DHW-2000HY-DHW-2500HY-DHW-2800HY-DHW-3300
    Weld width(mm)15002000250028003300
    Meshi trip(mm)Single trip 3000 and no limit on return
    Std trans.spacing>=25mm-stepless adjustable
    Std long.spacing>=50mm, and progressive increase by 50>=100mm, and increase by 100
    Std weld spots3141512732
    Wire diameter(mm)3.0-6.03.0-6.03.0-6.05.0-12.05.0-12.0
    Weld speed(times/min50-7040-6040-6040-6040-60
    Trans materialStraight bar/rodStraight bar
    Long materialStraight bar/rod
    Control modePLC programming servo motor stepper
    Mesh diagonal error<=2
    Mesh overall error<=2
    Air pressure>=0.7
    Weld materialCold drawn wire, galvanized wire, cold rolled ribbed steel


    3. Application area

    The wire diameter 4mm CNC spot welding machine can be widely used in the floor &wall reinforcing mesh in the building,reinforcing mesh in the tunnel,bridge and road.

    4. Advantages

    a. Both wires are pre-cut and finished mesh panel more nice.

    b. Save manual work and time.

    c. We can design the welded wire mesh machine as your requirement.

    d. Longtitude wire fed automatically by raw material feeding device.Finished mesh pulled automatically by pneumatic device.More loading capacity for the cross wires.Save more manual labor and time.

    e. Upper and down electrodes material is CuCrZr, best quality for electrical conductivity, abrasion-proof and long use life.
