PLC Automatic Spot Welding Machine , 200mm Aperture 380V Weld Mesh Making Machine

    Buy cheap PLC Automatic Spot Welding Machine , 200mm Aperture 380V Weld Mesh Making Machine from wholesalers

    Buy cheap PLC Automatic Spot Welding Machine , 200mm Aperture 380V Weld Mesh Making Machine from wholesalers
    • Buy cheap PLC Automatic Spot Welding Machine , 200mm Aperture 380V Weld Mesh Making Machine from wholesalers

    PLC Automatic Spot Welding Machine , 200mm Aperture 380V Weld Mesh Making Machine

    Ask Lasest Price
    Brand Name : Huayang
    Model Number : R-DHW
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 20 sets/month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    PLC Automatic Spot Welding Machine , 200mm Aperture 380V Weld Mesh Making Machine

    Automatic Blue Color Roll Mesh Welding Machine

    1. Product description

    Automatic blue color roll mesh welding machine is used for making wire mesh. The new electric welded wire mesh roll machine for construction is new designed and suitable for bigger range of diameter and different mesh hole size. The mesh pulling system is different from the traditional mesh pulling system by using rubber shaft pulling. The mesh aperture can be any size among 25-200mm.


    2. Technical parameter


    ModelMesh widthMinimum mesh size (inch)Wire diameter(mm)Welding speed (rows/min)Roll mesh length (m)Other available mesh size (inch)
    R- DHW11m1/2x1/20.45-0.8590-1201301/2x1, 1x1/2, 1x1, 2x2
    R- DHW11m1/2x1/20.6-1.390-1201101/2x1, 1x1/2, 1x1, 2x2
    R- DHW11m1/2x1/20.8-1.680-901001/2x1, 1x1/2, 1x1, 2x2
    R- DHW11m1x10.45-0.8590-1201301x2, 2x1, 2x2, 2x4
    R- DHW11m1x10.6-1.390-1101101x2, 2x1, 2x2, 2x4
    R- DHW11m1x10.8-1.6

    90-110

    1001x2, 2x1, 2x2, 2x4
    R- DHW11m1x11.4-2.680-90801x2, 2x1, 2x2, 2x4


    3. Application area

    The automatic blue color roll mesh welding machine is used for roll mesh welding line. It is also called automatic welded mesh machine,welded wire mesh roll machine,used to make road mesh,reinforcing mesh,construction mesh etc.


    4. Advantages

    a. Sturdy structure and world famous electric components are used like Simens, Schneider, Delta etc.

    b. Patent design for process of thick hard black wire.ne time two or three mesh rolls can be produced.


    c. We use intellectual property transformer with copper core, with superior quality.


    d. One time two or three mesh rolls can be produced.

    e. We are engaged in wire mesh welding machine for more than 20 years, providing you with the most professional knowledge and the most suitable machine.
