    PLC Dia 8mm Automatic Wire Mesh Welding Machine GI Wire Stainless Steel

    PLC Control Automatic Diamond Mesh Wire Making Machine

    1. Product description

    PLC control automatic diamond mesh wire making machine is used for making wire mesh. The welding electrode is made of high-quality Chromium Zirconium copper material, which has a long service life and reduces the production cost. Line wire feeding mode: The line wire adopts manual feeding and automatic feeding function. Accurate position saves welding waiting time.

    2. Technical parameter


    ModelHY-DHW-1500HY-DHW-2000HY-DHW-2500HY-DHW-2800HY-DHW-3300
    Weld width(mm)15002000250028003300
    Meshi trip(mm)Single trip 3000 and no limit on return
    Std trans.spacing>=25mm-stepless adjustable
    Std long.spacing>=50mm, and progressive increase by 50>=100mm, and increase by 100
    Std weld spots3141512732
    Wire diameter(mm)3.0-6.03.0-6.03.0-6.05.0-12.05.0-12.0
    Weld speed(times/min50-7040-6040-6040-6040-60
    Trans materialStraight bar/rodStraight bar
    Long materialStraight bar/rod
    Control modePLC programming servo motor stepper
    Mesh diagonal error<=2
    Mesh overall error<=2
    Air pressure>=0.7
    Weld materialCold drawn wire, galvanized wire, cold rolled ribbed steel


    3. Application area

    The PLC control automatic diamond mesh wire making machine can be used in mesh fence, casting roof mesh in the building, Construction ( 3d panel covered mesh, floor warmness preserving mesh, seedbed mesh, floor room mesh,animal cages).


    4. Advantages

    a. We choose well known brand from home and abroad to ensure the entirety steel property to avoid any transformation, transposition happen during transportation, installation process as to affect the precision of the machine.

    b. To produce mesh by coiled wire continuously.

    c. The greatest advantage is possible to adjust the distance of line wires at random on the same mesh panel.

    d. To strengthen easy operation of machine, we use proximity switch between upper and lower welding heads, when cross wire doesn’t reach, the machine will stop automatically.

    e. The machine line automatic degree can be according to request. For the economical type, line wire and cross wire are pre straightened and cut to length. We are capable to produce fully automatic machine.
