    Huayang 1.5m Width Pneumatic Spot Welding Machine 70rows/min

    Automatic 1.5 meter width Pneumatic Spot Welding Machine

    1. Product description

    Automatic 1.5 meter width pneumatic spot welding machine is used for making panel mesh. Computer great automatic welding panel machine is the advanced welded equipment which is the combination of machinery, electricity computer. The biggest merit is that the wire diameter can change, you can get the hole distance when you insert the distance, if you can change the data, so you can get the distance what you need, welded many big hole, then welded many small hole, you can change at your will.

    2. Technical parameter


    ModelHY-DHW-1500HY-DHW-2000HY-DHW-2500HY-DHW-2800HY-DHW-3300
    Weld width(mm)15002000250028003300
    Meshi trip(mm)Single trip 3000 and no limit on return
    Std trans.spacing>=25mm-stepless adjustable
    Std long.spacing>=50mm, and progressive increase by 50>=100mm, and increase by 100
    Std weld spots3141512732
    Wire diameter(mm)3.0-6.03.0-6.03.0-6.05.0-12.05.0-12.0
    Weld speed(times/min50-7040-6040-6040-6040-60
    Trans materialStraight bar/rodStraight bar
    Long materialStraight bar/rod
    Control modePLC programming servo motor stepper
    Mesh diagonal error<=2
    Mesh overall error<=2
    Air pressure>=0.7
    Weld materialCold drawn wire, galvanized wire, cold rolled ribbed steel


    3. Application area

    The automatic 1.5 meter width pneumatic spot welding machine can be used in for concrete reinforcement, panels in construction and security wire mesh fences, in a small area and noiseless.

    4. Advantages

    a. To increase safety of machine, we protect every transmission part (chain, rotate) with protective cover; and add switch in the electric cabinet, so when there is any wrong operation, the cabinet and machine will immediately cut off to avoid any electric shock.

    b. The weft wire of wire mesh welding machine feeding from the multi hopper which capacity is more over ten times than the traditional hopper.

    c. Guarantee the welded wire mesh machine for one year.

    d. The new wire mesh welding machine added the bear wire net and carry equipment that makes the working more convenience .

    e. The welding part of wire mesh welding machine is used the springiness input wire trunking that makes the welding copper use for long time.
