    2.5m Width Geoponics Precision Spot Welder , Huayang Wire Mesh Spot Welding Machine

    Ask Lasest Price
    Brand Name : Huayang
    Model Number : R-DHW
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 20 sets/month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    2.5m Width Geoponics Precision Spot Welder , Huayang Wire Mesh Spot Welding Machine

    Automatic 2.5 Meters Width Pneumatic Spot Welding Machine

    1. Product description

    Automatic 2.5 meters width pneumatic spot welding machine is used for making wire mesh. The surface is smooth, the error of opposite angle line. It is evaluated the advanced welding mesh equipments by the mesh-welding expert. If you need the equipments of more than 2.5m and 6mm, you can order goods.the widest of panel is 2.5m. the diameter of welded is 2.5mm-6mm.welding transformer air is self-controlling. weld the form time contracts, welds at different times. the pressure of welding can change.the hole distance of mesh inputs the computer the hole distance changed automatic.



    2. Technical parameter


    ModelHY-DHW-1500HY-DHW-2000HY-DHW-2500HY-DHW-2800HY-DHW-3300
    Weld width(mm)15002000250028003300
    Meshi trip(mm)Single trip 3000 and no limit on return
    Std trans.spacing>=25mm-stepless adjustable
    Std long.spacing>=50mm, and progressive increase by 50>=100mm, and increase by 100
    Std weld spots3141512732
    Wire diameter(mm)3.0-6.03.0-6.03.0-6.05.0-12.05.0-12.0
    Weld speed(times/min50-7040-6040-6040-6040-60
    Trans materialStraight bar/rodStraight bar
    Long materialStraight bar/rod
    Control modePLC programming servo motor stepper
    Mesh diagonal error<=2
    Mesh overall error<=2
    Air pressure>=0.7
    Weld materialCold drawn wire, galvanized wire, cold rolled ribbed steel


    3. Application area

    The automatic 2.5 meters width pneumatic spot welding machine extensively used in algriculture. The machine produce the wire mesh. The people can use the wire mesh to make animal cages. Such as: chicken cage, dog cage, rabbit cage, etc. It is easy operation and economical.

    4. Advantages

    a. We can design the welded wire mesh machine as your requirement.

    b. Transverse reinforcement raw material storage frame with funnel method, you can store a lot of raw materials.

    c. User-friendly English manual for welded wire mesh machine using and maintaining.

    d. Welding part can easily switch, which greatly improves the service life of machinery, maximum reduce the cost.


    e. The machine line automatic degree can be according to request. For the economical type, line wire and cross wire are pre straightened and cut to length. We are capable to produce fully automatic machine.
