    Low Carbon Steel Domestic CNC Spot Welding Machine Wire Dia 3mm

    Ask Lasest Price
    Brand Name : Huayang
    Model Number : R-DHW
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 20 sets/month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Low Carbon Steel Domestic CNC Spot Welding Machine Wire Dia 3mm

    Automatic Low Carbon Steel CNC Spot Welding Machine

    1. Product description

    Automatic low carbon steel CNC spot welding machine is used for making panel mesh. It can mesh with a wire diameter direction appear on different size mesh.The greatest feature of the aircraft broke the plate wire fence films can not be used for continous production of the situation and change the wire diameter varies due to replace each of the contact pressure spring chores,minor changes in cylinder pressure knob, you can change the solder joint stress.

    2. Technical parameter


    ModelHY-DHW-1500HY-DHW-2000HY-DHW-2500HY-DHW-2800HY-DHW-3300
    Weld width(mm)15002000250028003300
    Meshi trip(mm)Single trip 3000 and no limit on return
    Std trans.spacing>=25mm-stepless adjustable
    Std long.spacing>=50mm, and progressive increase by 50>=100mm, and increase by 100
    Std weld spots3141512732
    Wire diameter(mm)3.0-6.03.0-6.03.0-6.05.0-12.05.0-12.0
    Weld speed(times/min50-7040-6040-6040-6040-60
    Trans materialStraight bar/rodStraight bar
    Long materialStraight bar/rod
    Control modePLC programming servo motor stepper
    Mesh diagonal error<=2
    Mesh overall error<=2
    Air pressure>=0.7
    Weld materialCold drawn wire, galvanized wire, cold rolled ribbed steel


    3. Application area

    The automatic low carbon steel CNC spot welding machine can be used for production of dimensionally accurate meshwork for a wide variety of applications. Wire mesh may be used to produce shop, exhibition- and warehouse equipment as well as trays for domestic and overseas appliances.


    4. Advantages

    a. This line adopt special welding process ,Efficient water cooling system and precision welding control system and high quality copper alloy electrodes with unique appearance.

    b. The line wire and the weft wire of wire mesh welding machine are pre-straight and pre-cut.

    c. We can design the welded wire mesh machine as your requirement.

    d. Welding part can easily switch, which greatly improves the service life of machinery, maximum reduce the cost.

    e. The wire mesh welding machine welding power comes from the cylinders. It's easy to control the welding pressure .
